BEZ100 MITRE SAW Type 1 | Drawings

Documents

Item No.	Product Number	Qty Per	Product Description	Markets
1	1004769-26	1	BODY	XJ
2	1004704-68	1	HANDLE	XJ
3	1004704-67	2	SCREW	XJ
4	1004704-83	4	LOCK KNOB	XJ
5	N732517	1	BRAND LABEL	XJ
6	N732516	1	RATING PLATE	XJ
7	1004769-24	4	LEG	XJ
8	1004704-60	4	CAP	XJ
9	1004704-66	4	FOOT	XJ
10	1004704-88	4	SCREW	XJ
11	1004704-89	4	NUT	XJ
12	1004704-61	4	LOCK PIN	XJ
13	1004704-62	4	SPRING	XJ
14	1004704-63	4	LEVER LOCK	XJ
15	1004704-64	4	CIRCLIP	XJ
16	1004769-28	2	TABLE INNER	XJ
17	1004704-58	4	CAP	XJ
18	1004704-57	4	CAP	XJ
19	1004704-59	4	CAP	XJ
21	1004704-82	4	LOCK KNOB	XJ
22	1004769-30	2	BRACKET	XJ
26	1004704-53	2	BRACKET SA	XJ
27	000000-00	1	NO LONGER AVAILABLE	XJ
28	1004704-77	2	CLIP	XJ
29	1004704-75	4	FOOT	XJ
30	1004704-76	8	SCREW	XJ
31	1004704-78	2	SPRING COMPRESSION	XJ
32	1004704-81	2	LEVER RELEASE	XJ
33	1004704-79	4	BOLT	XJ
34	1004704-80	4	NUT	XJ
35	1004769-31	1	BAG	XJ
37	1004704-69	4	BOLT	XJ
38	1004704-71	4	WASHER SPRING	XJ
39	1004704-72	4	NUT	XJ
55	1004769-25	1	SOCKET	XJ
58	1004769-27	4	LEG	XJ
