KA2500 PALM GRIP SANDER Type 1 | Drawings
Documents
Parts List
Save PDF
View Full Page
| Item No. | Product Number | Qty Per | Product Description | General Description | Other Info | Markets | Product Status |
|---|---|---|---|---|---|---|---|
| 1 | 000000-05 | 1 | PARTIAL SUPPORT - ONLY PARTS LISTED AVAI | GB | |||
| 1 | 55598-PWR | 1 | SCREW | M5 x 25 | GB |  |
|
| 2 | N495293 | 1 | CANISTER | GB |  |
||
| 2 | 56248-PWR | 1 | SCREW | GB | |
||
| 3 | 90604245 | 1 | PLATEN | GB | |
||
| 4 | 90602498 | 1 | CARRIER SA | GB | |
||
| 4 | 56344-PWR | 1 | MAGAZINE SA | GB | |
||
| 5 | 571081-02 | 1 | SCREW | M3 x 10 | GB | |
|
| 5 | 56119-PWR | 1 | TUBE | GB | |
||
| 6 | 582193-00 | 3 | SCREW | GB | |
||
| 6 | 56174-PWR | 1 | NUT M5 | GB | |
||
| 7 | 582146-01 | 1 | FINGER | GB | |
||
| 7 | 56250-PWR | 1 | COVER | GB | |
||
| 8 | 55504-PWR | 1 | FILTER | GB | |
||
| 9 | 56100-PWR | 1 | BOLT | GB | |
||
| 10 | 56152-PWR | 1 | CYLINDER | GB | |
||
| 11 | 55551-PWR | 1 | SPRING | GB | |
||
| 12 | 56101-PWR | 1 | WASHER | GB | |
||
| 13 | 55812-PWR | 1 | CYLINDER | GB | |
||
| 14 | 56103-PWR | 1 | END CAP | GB | |
||
| 15 | 55807-PWR | 1 | RING | GB | |
||
| 16 | 56361-PWR | 1 | PISTON SA | GB | |
||
| 17 | 56186-PWR | 1 | NOSE | GB | |
||
| 18 | 56192-PWR | 1 | BUMPER | GB | |
||
| 19 | 56188-PWR | 1 | BOLT | GB | |
||
| 20 | 56194-PWR | 1 | COVER | GB | |
||
| 21 | 56368-PWR | 1 | SCREW KIT | GB | |
||
| 22 | 56281-PWR | 1 | CAP | GB | |
||
| 23 | 56245-PWR | 1 | SCREW | GB | |
||
| 24 | 55628-PWR | 1 | SWITCH | GB | |
||
| 25 | 56283-PWR | 1 | LATCH | GB | |
||
| 26 | 56239-PWR | 1 | PROTECTOR | GB | |
||
| 27 | 56208-PWR | 1 | SCREW | GB | |
||
| 28 | 55644-PWR | 1 | ADAPTOR | GB | GB | |
|
| 29 | 55600-PWR | 1 | NUT PACK | M4 | GB | |
|
| 30 | 55511-PWR | 1 | ADAPTOR | GB | |
||
| 31 | 55587-PWR | 1 | SPARK PLUG | GB | |
||
| 33 | 55602-PWR | 1 | SCREW KIT | GB | |
||
| 34 | 55588-PWR | 1 | CONNECTOR | GB | |
||
| 35 | 55694-PWR | 1 | MAGAZINE | HAFTSP56A | GB | |
|
| 37 | 55518-PWR | 1 | CYLINDER | GB | |
||
| 38 | 55519-PWR | 1 | SEAL | GB | |
||
| 39 | 56204-PWR | 1 | CONNECTOR | GB | |
||
| 40 | 55520-PWR | 1 | RING | GB | |
||
| 41 | 56293-PWR | 1 | MOUNT | GB | |
||
| 42 | 55620-PWR | 1 | ADAPTOR SA | + CORDSET | GB | |
|
| 43 | 56360-PWR | 1 | VALVE REED | GB | |
||
| 44 | 56122-PWR | 1 | O RING | GB | |
||
| 45 | 56355-PWR | 1 | STOP | GB | |
||
| 47 | 56364-PWR | 1 | ADJUSTER DEPTH | GB | |
||
| 48 | 56212-PWR | 1 | LEVER | GB | |
||
| 49 | 56363-PWR | 1 | LOCKING DEVICE | GB | |
||
| 50 | 55839-PWR | 1 | HOUSING SA | GB | |
||
| 51 | 55642-PWR | 1 | WARNING LABEL | GB | |
||
| 52 | 55610-PWR | 1 | LEVER KIT | Short Track | GB | |
|
| 53 | 56193-PWR | 1 | SHAFT | GB | |
||
| 54 | 56331-PWR | 1 | SCREW | GB | |
||
| 55 | 56312-PWR | 1 | MAGAZINE INTERFACE | GB | |
||
| 56 | 56215-PWR | 1 | CONTACT PLATE | GB | |
||
| 58 | 56114-PWR | 1 | PLUG | GB | |
||
| 59 | 55590-PWR | 1 | PISTON RING | Kit | GB | |
|
| 60 | 56132-PWR | 1 | O RING | GB | |
||
| 61 | 56136-PWR | 1 | SEAL | GB | |
||
| 62 | 56346-PWR | 1 | MAGAZINE SA | GB | |
||
| 64 | 56138-PWR | 1 | HOUSING LOWER | GB | |||
| 66 | 56370-PWR | 1 | COVER | GB | |
||
| 67 | 56237-PWR | 1 | BAR LOCKING | GB | |
||
| 68 | 56354-PWR | 1 | BATTERY CONNECTOR | GB | |
||
| 69 | 56226-PWR | 1 | SPRING TORSION | GB | |
||
| 71 | 56167-PWR | 1 | HANDLE RH | GB | |
||
| 72 | 56329-PWR | 1 | SPRING COMPRESSION | GB | |
||
| 73 | 56170-PWR | 1 | GUIDE | GB | |
||
| 74 | 56183-PWR | 1 | SCREW | GB | |
||
| 81 | 55816-PWR | 1 | CAGE | GB | |
||
| 82 | 56287-PWR | 1 | PIN | GB | |
||
| 83 | 56190-PWR | 1 | NOSE | GB | |
||
| 84 | 56353-PWR | 1 | FOLLOWER | GB | |
||
| 85 | 60012-PWR | 1 | HOUSING REPAIR KIT | Wurth | x2 | GB | |
| 90 | 56359-PWR | 1 | SPRING GUIDE | GB | |
||
| 107 | 56218-PWR | 1 | SPRING COMPRESSION | GB | |
||
| 861 | 56200-PWR | 1 | SOLENOID ASSEMBLY | GB | |
