WM540 WORKMATE Type 1 | Drawings
Documents
Parts List
Save PDF
View Full Page
| Item No. | Product Number | Qty Per | Product Description | General Description | Other Info | Markets | Product Status |
|---|---|---|---|---|---|---|---|
| 1 | 596735-00 | 1 | VICE JAW FRONT | XJ |  |
||
| 2 | 596736-00 | 1 | VICE JAW REAR | XJ | |
||
| 5 | 5140025-05 | 1 | BRACKET LH | XJ | |
||
| 6 | 5140025-06 | 1 | BRACKET RH | XJ | |
||
| 7 | 242302-00 | 2 | ARM | XJ |  |
||
| 8 | 242440-00 | 2 | KNOB | XJ | |
||
| 9 | 807530-02 | 4 | GRIP | XJ | |
||
| 10 | 5140025-10 | 1 | VICE SCREW | XJ | |
||
| 11 | 242311-00 | 2 | PIN | XJ | |
||
| 12 | 5140025-12 | 2 | NUT | VICE SREW NUT | XJ | |
|
| 13 | 5140025-13 | 2 | COVER | XJ | |
||
| 14 | 5140006-86 | 4 | BOLT | XJ | |
||
| 15 | 5140025-15 | 1 | FRAME SA | LEFT FRAME | XJ | |
|
| 16 | 5140025-16 | 2 | END CAP | XJ | |
||
| 17 | 5140025-17 | 2 | FOOT | XJ | |
||
| 18 | 5140025-18 | 2 | WHEEL | XJ | |
||
| 19 | 5140025-19 | 2 | NUT | M8 | XJ | |
|
| 20 | 5140025-20 | 2 | WASHER | XJ | |
||
| 21 | 5140025-21 | 2 | STOP RUBBER | XJ | |
||
| 22 | 5140025-22 | 4 | SCREW | XJ | |
||
| 23 | 5140025-23 | 2 | FRAME | SECONDARY FRAME | XJ | |
|
| 24 | 5140025-24 | 2 | END CAP | XJ | |
||
| 25 | 5140025-25 | 2 | FOOT | XJ | |
||
| 26 | 5140025-26 | 4 | RIVET | XJ | |
||
| 27 | 5140025-27 | 1 | LEVER SA | XJ | |
||
| 28 | 5140025-28 | 1 | COVER | PROTECTIVE COVER | XJ | |
|
| 29 | 5140025-29 | 1 | COVER | XJ | |
||
| 30 | 5140025-30 | 1 | COVER | XJ | |
||
| 31 | 5140025-31 | 1 | SPRING | LEVER SPRING | XJ | |
|
| 32 | 5140025-32 | 2 | LOCK PIN | XJ | |
||
| 33 | 5140025-33 | 6 | BOLT | S2.9x9.5 | XJ | |
|
| 34 | 5140025-34 | 1 | WASHER | XJ | |
||
| 35 | 5140025-35 | 3 | RING | XJ | |
||
| 36 | 5140025-36 | 1 | PLATE | TOE PLATE | XJ | |
|
| 37 | 5140025-37 | 1 | SLIDER | FOOT SLIDER | XJ | |
|
| 38 | 5140025-38 | 1 | SPRING | FOOT SLIDER SPRING | XJ | |
|
| 39 | 5140025-39 | 1 | LOCKING PIN | LOCK PIN STORAGE | XJ | |
|
| 40 | 5140025-40 | 3 | SPIROL PIN | SPRING BRACKET | XJ | |
|
| 41 | 5140025-41 | 1 | COVER | LIFT PLATE | XJ | |
|
| 42 | 5140025-42 | 3 | BOLT | XJ | |
||
| 43 | 5140025-43 | 2 | BOLT | WHEEL BOLT | XJ | |
|
| 44 | 5140025-44 | 2 | RING | XJ | |
||
| 45 | 5140025-45 | 2 | BOLT | XJ | |
||
| 46 | 5140025-46 | 2 | SLEEVE | XJ | |
||
| 47 | 5140025-47 | 2 | BOLT | XJ | |
||
| 48 | 5140025-48 | 2 | BOLT | XJ | |
||
| 49 | 5140025-49 | 6 | NUT | M6 | XJ | |
|
| 50 | 5140025-50 | 2 | WASHER PLASTIC | PLASTIC WASHER | XJ | |
|
| 51 | 5140025-51 | 2 | WASHER PLASTIC | PLASTIC WASHER | XJ | |
|
| 53 | 1004683-00 | 2 | BLOCK REAR | XJ | |
||
| 54 | 820262 | 2 | BLOCK FRONT | XJ | |
||
| 66 | 596737-00 | 1 | PARTS PACK | XJ | |
