GA1400E SHREDDER Type 1 | Drawings
Documents
Parts List
Save PDF
View Full Page
| Item No. | Product Number | Qty Per | Product Description | General Description | Other Info | Markets | Product Status |
|---|---|---|---|---|---|---|---|
| 1 | 567857-00 | 1 | FLAP | GB |  |
||
| 2 | 567858-00 | 3 | SCREW | GB | |
||
| 3 | 567859-00 | 3 | WASHER | GB | |
||
| 4 | 567860-00 | 2 | NUT | GB | |
||
| 5 | 567861-00 | 1 | CHUTE | GB | |
||
| 6 | 567862-00 | 1 | COVER | GB | |
||
| 7 | 560100-00 | 4 | SCREW | GB | |
||
| 8 | 560101-00 | 4 | SCREW | GB | |
||
| 9 | 567863-00 | 1 | WARNING LABEL | GB | |
||
| 10 | 567864-00 | 1 | SWITCH | GB | |
||
| 11 | 560103-00 | 6 | SCREW | GB | |
||
| 12 | 560104-00 | 4 | WASHER | GB | |
||
| 13 | 560105-00 | 4 | NUT | GB | |
||
| 14 | 567876-00 | 1 | PLATE | GB | |
||
| 15 | 560107-00 | 2 | WHEEL | GB | |
||
| 16 | 560108-00 | 2 | SPACER | GB | |
||
| 17 | 279718-00 | 2 | SPACER 144460 | GB | |
||
| 18 | 000000-00 | 1 | NO LONGER AVAILABLE | GB | |||
| 19 | 279707-00 | 1 | SCREW | GB | |
||
| 20 | 279706-00 | 1 | WASHER | GB | |
||
| 22 | 567878-00 | 1 | MOTOR COVER | GB | |
||
| 23 | 567879-00 | 1 | NUT | GB | |
||
| 24 | 567943-00 | 1 | AXLE | GB | |
||
| 25 | 568402-00 | 1 | LEG KIT | BEFORE WEEK 13/98 | GB | |
|
| 25 | 567881-00 | 1 | LEG RIGHT HAND | AFTER WEEK 13/98 | GB | |
|
| 26 | 567880-00 | 1 | LEG LEFT HAND | AFTER WEEK 13/98 | GB | |
|
| 26 | 568402-00 | 1 | LEG KIT | BEFORE WEEK 13/98 | GB | |
|
| 27 | 567883-00 | 1 | MOTOR | GB | |
||
| 28 | 560137-00 | 1 | CAPACITOR | GB | |
||
| 31 | 569031-00 | 1 | PIN | GB | |
||
| 32 | 567889-00 | 1 | BASEPLATE | GB | |
||
| 33 | 567944-00 | 2 | SPRING CLIP | GB | |
||
| 34 | 560119-00 | 2 | BLADE | GB | |
||
| 35 | 560120-00 | 4 | SCREW | GB | |
||
| 36 | 279696-00 | 1 | WASHER | GB | |
||
| 37 | 560121-00 | 1 | SCREW | GB | |
||
| 38 | 560122-00 | 1 | BOSS | GB | |
||
| 39 | 560123-00 | 1 | BLADE CARRIER | GB | |
||
| 40 | 560124-00 | 1 | SPACER | GB | |
||
| 41 | 560125-00 | 1 | WASHER | GB | |
||
| 42 | 560148-00 | 1 | FAN | GB | |
||
| 43 | 567892-00 | 1 | CLIP | GB | |
||
| 44 | 279804-00 | 1 | SPANNER | GB | |
||
| 45 | 279803-00 | 1 | HEX KEY 3 MM | GB | |
||
| 46 | 568016-00 | 1 | PUSHROD | GA2100E | GB | |
|
| 46 | 560130-00 | 1 | PUSHROD | GA1400E | GB | |
|
| 46 | 560130-00 | 1 | PUSHROD | GA1600E | GB | |
|
| 46 | 560130-00 | 1 | PUSHROD | GA1800E | GB | |
|
| 47 | 567953-00 | 4 | BOLT | GB | |
||
| 48 | 567954-00 | 4 | NUT | GB | |
