MOF112 ROUTER Type 1 | Drawings
Documents
Parts List
Save PDF
View Full Page
| Item No. | Product Number | Qty Per | Product Description | General Description | Other Info | Markets | Product Status |
|---|---|---|---|---|---|---|---|
| 1 | 868626-00 | 1 | ARMATURE 220/240V | GB |  |
||
| 2 | 868391-00 | 1 | FIELD 230V | GB | |
||
| 3 | 868026-00 | 1 | SWITCH | FRANK | GB | |
|
| 3 | 868026-00 | 1 | SWITCH | ELU | GB | |
|
| 4 | 868012-00 | 2 | BRUSH | GB | |
||
| 5 | 011101906 | 1 | CABLE | M | GB | |
|
| 5 | 011101908 | 1 | CABLE | M | GB | |
|
| 5 | 248987-00 | 1 | CORDSET | FRANK DE-FR | GB | |
|
| 5 | 325612-09 | 1 | CORDSET (M/PLUG) | GB | |
||
| 6 | 942277-00 | 1 | PROTECTOR | GB |  |
||
| 7 | 249136-00 | 1 | PLATE | GB | |
||
| 8 | 249413-05 | 2 | SCREW | GB | |
||
| 9 | 868008-00 | 1 | COVER | GB | |
||
| 10 | 018121906 | 1 | CAPACITOR | GB | |
||
| 11 | 249413-02 | 2 | SCREW | GB | |
||
| 12 | 249087-00 | 1 | SPACER | GB | |
||
| 13 | 868009-00 | 2 | BRUSH CAP | GB | |
||
| 14 | 248959-00 | 1 | HOUSING SA | GB | |
||
| 15 | 868014-00 | 1 | NUT | GB | |
||
| 16 | 248958-00 | 1 | COVER | GB | |
||
| 17 | 860155-08 | 1 | BEARING | GB | |
||
| 19 | 249412-20 | 3 | SCREW | GB | |
||
| 20 | 868002-00 | 1 | BAR | GB | |
||
| 21 | 868003-00 | 1 | SPANNER | GB | |
||
| 22 | 249571-00 | 1 | WASHER | GB | |
||
| 23 | 868768-01 | 1 | BEARING | 6002-2RSL/C3 | GB | |
|
| 24 | 868005-00 | 2 | SCREW | GB | |
||
| 25 | 868016-00 | 2 | RIVET | GB | |
||
| 26 | 011121000 | 1 | BEARING BUSH | GB | |
||
| 27 | 868013-00 | 1 | BUSH | GB | |
||
| 28 | 011811200 | 1 | SCREW | GB | |
||
| 29 | 011162500 | 1 | TERMINAL BLOCK | ELU | GB | |
|
| 29 | 326057-01 | 1 | TERMINAL BLOCK | FRANK | GB | |
|
| 30 | 868010-00 | 1 | HOUSING SWITCH | GB | |
||
| 31 | 941544-00 | 1 | CABLE CLAMP | GB | |
||
| 32 | 013811602 | 2 | SCREW | GB | |
||
| 34 | 869355-00 | 1 | REPAIR KIT | GB | |
||
| 35 | 868015-00 | 2 | LEAD | GB | |
||
| 36 | 868028-00 | 1 | CLIP | GB | |
||
| 37 | 860089-25 | 1 | SCREW | GB | |
||
| 38 | 249304-00 | 1 | CONNECTOR | GB | |
||
| 41 | 868027-00 | 1 | CAPACITOR | GB | |
||
| 42 | 249233-00 | 1 | WASHER | GB | |
||
| 43 | 249424-00 | 1 | SCREW | GB | |
||
| 45 | 868011-00 | 2 | BRUSH HOLDER | GB | |
||
| 46 | 013814600 | 2 | SCREW | GB | |
||
| 50 | 011106000 | 1 | CAPACITOR KIT | GB | |
||
| 51 | 011167500 | 1 | REGULATOR | FRANK | GB | |
|
| 52 | 868015-01 | 1 | LEAD RED | FRANK | GB | |
|
| 53 | 868015-02 | 1 | LEAD YELLOW | FRANK | GB | |
|
| 54 | 868015-03 | 1 | LEAD BLUE | FRANK | GB | |
|
| 55 | 011930171 | 2 | WASHER | GB | |
