DW1150----A PLANER THICKNESSER Type 1 | Drawings
Documents
Parts List
Save PDF
View Full Page
| Item No. | Product Number | Qty Per | Product Description | General Description | Other Info | Markets | Product Status |
|---|---|---|---|---|---|---|---|
| 1 | 860094-05 | 1 | SCREW | XJ |  |
||
| 2 | 860060-01 | 2 | RIVET | XJ |  |
||
| 3 | 33456 | 1 | NAMEPLATE | XJ | |
||
| 4 | 123313-00 | 1 | COVER | XJ | |
||
| 5 | 860133-00 | 1 | CAP | XJ | |
||
| 6 | 860692-00 | 1 | KLIXON | XJ | |
||
| 7 | 860094-01 | 2 | SCREW | XJ | |
||
| 8 | 944650-00 | 1 | WASHER SPRING | XJ | |
||
| 9 | 863877-00 | 1 | RING | XJ | |
||
| 10 | 949747-07 | 1 | GLAND | XJ | |
||
| 11 | 949863-46 | 1 | CABLE | XJ | |
||
| 12 | 944653-00 | 1 | GROMMET | XJ | |
||
| 13 | 944652-00 | 1 | GROMMET | XJ | |
||
| 15 | 860088-25 | 1 | SCREW | XJ | |
||
| 16 | 860687-03 | 1 | END CAP | XJ | |
||
| 17 | 860094-05 | 2 | SCREW | XJ | |
||
| 18 | 860688-00 | 1 | FAN | XJ | |
||
| 19 | 860083-02 | 2 | NUT | XJ | |
||
| 20 | 860073-01 | 2 | WASHER | XJ | |
||
| 21 | 860701-00 | 1 | HOUSING | XJ | |
||
| 22 | 860718-00 | 1 | SEAL | XJ | |
||
| 23 | 860080-02 | 1 | RING | XJ | |
||
| 24 | 861721-01 | 1 | BEARING | XJ | |
||
| 25 | 860446-01 | 1 | BOLT | XJ | |
||
| 26 | 868425-01 | 1 | ROTOR | XJ | |
||
| 27 | 860539-01 | 1 | KEY | XJ | |
||
| 28 | 860704-00 | 1 | STATOR SA 220V | 220V | XJ | |
|
| 28 | 864397-61 | 1 | STATOR SA 240V | 240V | XJ | |
|
| 29 | 860073-14 | 1 | WASHER | XJ | |
||
| 30 | 860093-15 | 1 | SCREW | XJ | |
||
| 31 | 123294-00 | 1 | SPACER | XJ | |
||
| 32 | 942043-00 | 1 | SCREW | XJ | |
||
| 33 | 949702-19 | 2 | SCREW | XJ | |
||
| 34 | 123292-00 | 2 | SPACER | XJ | |
||
| 35 | 176576 | 1 | PULLEY | XJ | |
||
| 36 | 860538-00 | 2 | SCREW | XJ | |
||
| 37 | 860699-02 | 1 | ARBOR | XJ | |
||
| 38 | 860073-03 | 2 | WASHER M8 | XJ | |
||
| 39 | 860083-04 | 2 | NUT | XJ | |
||
| 40 | 131759 | 1 | SPACER | XJ | |
||
| 41 | 868768-10 | 1 | BEARING | XJ | |
||
| 42 | 863878-00 | 1 | GASKET | XJ | |
||
| 43 | 133543 | 1 | CAP | XJ | |
||
| 44 | 860540-00 | 1 | CONNECTOR | XJ | |
||
| 45 | 944455-00 | 1 | CONDENSOR | XJ | |
||
| 46 | 860706-00 | 1 | SWITCH 1 PH | XJ | |
||
| 47 | 862451-00 | 1 | CAP | XJ | |
||
| 48 | 860702-00 | 1 | HOUSING | XJ | |
||
| 49 | 860094-00 | 1 | SCREW.TEMP | XJ | |
||
| 50 | 860708-00 | 1 | GASKET | XJ | |
||
| 51 | 860073-00 | 1 | WASHER | XJ | |
||
| 52 | 860089-25 | 1 | SCREW | XJ | |
||
| 53 | 197831 | 1 | MOTOR 1 PH | XJ | |
||
| 54 | 944454-00 | 1 | COVER | TELESWITCH 1PH. | XJ | |
|
| 55 | 144432 | 1 | CABLE | TELESWITCH 1PH. | XJ | |
|
| 56 | 44895 | 1 | SWITCH 1 PH | TELESWITCH 1PH. | XJ | |
|
| 57 | 149199 | 1 | CABLE | TELESWITCH 1PH. | XJ | |
|
| 58 | 132051 | 1 | PLATE | XJ | |
||
| 59 | 11269 | 2 | SCREW | XJ | |
||
| 60 | 860089-01 | 2 | SCREW | XJ | |
